RE800L Multi-function Thermal Imaging Rangefinder
Onick RE800L multi-function thermal imaging rangefinder reconnaissance instrument adds infrared, low light, green laser rejection function, 4G wireless transmission, laser ranging, remote wireless button control function, pitch angle, roll angle, electronic compass azimuth, satellite positioning and other functions on the original basis, 8-36X zoom HD camera, more suitable for close-range day and night all-weather 24-hour evidence collection video.
€0
Product Details
Product Details
Onick RE800L multi-function thermal imaging rangefinder reconnaissance instrument adds infrared, low light, green laser rejection function, 4G wireless transmission, laser ranging, remote wireless button control function, pitch angle, roll angle, electronic compass azimuth, satellite positioning and other functions on the original basis, 8-36X zoom HD camera, more suitable for close-range day and night all-weather 24-hour evidence collection video. Supports APP remote real-time viewing, photo recording, the product is more practical, with clear imaging during the day and good image effect at night. This series of products has a high degree of integration, small size, and light weight. It is specially developed to meet the convenience of users to carry and operate, so as to meet the all-weather automatic evidence collection needs in various fields. Color images (or black and white images) during the day and black and white images at night: the maximum monitoring distance during the day can reach two kilometers. It is an excellent high-tech night vision monitoring product with a high cost-effectiveness after actual application testing among similar products. The equipment has a long life, good stability, good effect and excellent quality.
Product Features：
1、A lightweight intelligent observation device that integrates infrared, low light, laser ranging, and green laser rejection;
2、Supports remote wireless button control function, pitch angle, roll angle, electronic compass azimuth, etc.;
3、Supports 4G wireless transmission, supports APP remote real-time viewing, photo taking and video recording.
4、8-36X zoom HD camera, optical image stabilization, and fog penetration function.
Application areas:
It can be used in patrol, law enforcement, search and rescue, drug and smuggling, prisoner pursuit, reconnaissance, surveillance, outdoor hunting and security protection. It is suitable for special forces such as public security, armed police and the army to achieve effective all-weather observation of specific areas or targets, and quickly discover, identify and track targets of concern; it is also suitable for fire protection, electricity and petroleum industries to achieve day and night monitoring of specific areas or equipment.
| Detector type | Vanadium oxide |
| Sensitivity | ≤30mk@25℃, F#1.0 |
| Resolution | 384×288 / 640×512 (17μm / 12μm) |
| Field of view | 17.7°×14.2° |
| Operating band | 8～14μm |
| Lens focal length | 50mm electric focus, electric zoom, 15 pseudo color modes |
| Sensor type | 1/1.8" ultra-low illumination CMOS ICR infrared filter automatically switches between day and night modes |
| Resolution | 1920*1080 |
| Low illumination | 0.005Lux (color) 0.0001Lux (black and white) |
| Focal range | 5.8～210mm |
| Optical magnification | 36x |
| Electronic zoom | 8x |
| Day and night mode | Automatic ICR infrared filter type. When the laser is turned on, it automatically switches from color to black and white. When the laser is turned off, it automatically switches from black and white to color. |
| Power | Rated power 6W |
| Irradiation angle | 0.2～40°continuous change |
| Laser wavelength | 940nm no red burst invisible to human eyes |
| Opening method | Manual adjustment/APP remote control |
| Spot size | Manual adjustment/automatic follow |
| Azimuth sensor | Static accuracy 0.05° Dynamic 0.1° |
| Roll angle sensor | Range ±90° Static accuracy 0.05° Dynamic 0.1° |
| Pitch angle sensor | Range ±180° Static accuracy 0.05° Dynamic 0.1° |
| Positioning method | Beidou satellite positioning |
| Sensitivity | Tracking: -162dBm Capture: -148dBm |
| Storage | Built-in 64GSD card (supports expansion) |
| Battery power display | Supports one-key display/hide battery power display |
| Video recording and photo taking | Supports 2-megapixel HD video recording and full HD image taking. Local video playback function |
| Remote control function | Remote control of zoom, focus, rangefinder on/off, laser on/off, laser aperture adjustment function (test distance 40 meters) |
| Measuring range | 5～1200/1500/1800 meters optional |
| Measuring accuracy | ± 0.5M (within 400M); ±1M (600M-1000M) |
| Window function | Support infrared through-window reconnaissance video performance |
| Remote control | 4G wireless image transmission wireless remote control |
| Display screen | 5.5-inch high-definition display (visible in sunlight) |
| Built-in battery | ≥8 hours (built-in lithium battery) |
| Product size | 220mm×205mm×115mm |
| Protection level | IP66 |
| Host weight | ＜2.6kg |
| Operating temperature | -25℃～+65℃ |
| Storage temperature | -40℃～+70℃ |
| Off-screen work | One-click to turn off the display screen, the built-in camera can continue to work and enter energy-saving mode. |
| Character overlay | Support one-click display/hide character information. Support Beidou positioning latitude and longitude information, electronic compass direction information, azimuth information, battery power information, and distance measurement information real-time display |
